FC-115
K&LAN
| Quantity: | |
|---|---|
The FC-115 is a U-shaped channel seal made from EVA material, designed to seal the gap between glass panels and frame structures in shower and glass door applications. Featuring internal tooth-like ribs within its U-channel, this seal provides enhanced grip on glass edges without requiring adhesive. The clear transparent material allows the seal to blend with glass installations while maintaining visual clarity. Available in roll form with customizable length options, the FC-115 supports flexible sourcing for industrial applications and commercial procurement projects.
This product functions as both a sealing element and a cushioning buffer between glass edges and frame materials. Its U-shaped profile fits over the glass edge, and the internal rib structure holds the seal securely in place. When installed in a frame channel, the outer walls of the U press against the frame material to create a water-resistant barrier along the length of the glass edge.
Parameter | Specification |
Model | FC-115 |
Brand | K&LAN |
Material | EVA |
Color | Clear |
Product Length | Any length |
Packing | By roll |
The FC-115 incorporates tooth-like ribs along the inner surfaces of its U-channel. These ribs are designed to engage with the glass surface, creating friction that holds the seal in position. The ribbed structure provides multiple contact points along the glass edge, distributing holding force evenly and preventing the seal from shifting during door operation or water exposure.
Constructed from EVA (ethylene-vinyl acetate), the FC-115 offers a combination of flexibility and resilience. EVA material is resistant to water absorption and maintains its physical properties in environments with elevated humidity and temperature levels, such as bathrooms and shower rooms. The clear transparent formulation ensures the seal does not detract from the aesthetic appearance of glass installations.
The U-shaped cross-section of the FC-115 is proportioned to fit over standard glass thicknesses and sit within frame channels. The channel provides full coverage of the glass edge, protecting it from direct contact with frame materials and reducing the risk of chipping or damage. The outer walls of the U are designed to make consistent contact with frame surfaces, creating a continuous seal along the installation length.
The primary application of the FC-115 is in shower rooms and shower enclosures where glass panels are set in aluminum or wooden frames. The seal fills the gap between the glass edge and the frame channel to contain water spray and reduce moisture transfer outside the shower area. This makes it suitable for both residential bathrooms and commercial facilities such as hotels, gyms, and spa centers.
In commercial buildings including offices, restaurants, and public facilities, the FC-115 can be used on glass partition walls and doors in bathroom areas. The clear material maintains the open, modern appearance of glass partitions while providing functional sealing at frame junctions.
For hotel and hospitality projects requiring multiple shower door installations, the FC-115 offers consistent performance across large-scale installations. The roll format and customizable length options support efficient project planning and bulk procurement for business operations.
The FC-115 is also applicable to glass office partition systems where glass panels meet frame structures. It provides a cushioning seal that reduces noise transfer and gives a finished appearance to glass-frame intersections, while the clear material preserves the open feel of the workspace.
Begin by measuring the glass edge and cutting the FC-115 seal to the required length. Clean the glass surface thoroughly to remove any contaminants. Align the U-channel with the glass edge and press the seal firmly along its entire length until fully seated. The internal ribs will engage with the glass surface to hold the seal in place. Once the seal is on the glass, insert the assembly into the frame channel, ensuring the seal sits properly within the frame.
Regular cleaning of the seal with mild soap and water helps maintain its appearance and performance. Avoid using abrasive cleaners or harsh chemicals that could damage the EVA material. Inspect the seal periodically for signs of wear or displacement, and reposition or replace sections as needed to maintain consistent sealing performance.
The FC-115 U seal is manufactured from EVA (ethylene-vinyl acetate) material. This material provides flexibility, water resistance, and dimensional stability for shower door and glass sealing applications. The seal is produced in a clear transparent finish.
To install the FC-115, first cut the seal to the required length. Clean the glass edge surface, then align the U-channel of the seal with the glass edge and press firmly along the entire length. The internal tooth-like ribs grip the glass surface and hold the seal in place without adhesive. Once seated on the glass, insert the assembly into the frame channel.
Yes, the FC-115 is designed for compatibility with both aluminum and wooden frame structures. The EVA material forms a sealing surface against both metal and wood frame materials, filling the gap between the glass edge and the frame channel.
Yes, the FC-115 is suitable for commercial bathroom projects including hotels, fitness centers, office buildings, and other facilities with shower or glass partition installations. The product is available in roll form with customizable length options to support bulk ordering for commercial procurement requirements.
